Technical parameters/number of contacts: 32
Technical parameters/polarity: Male
Technical parameters/Contact electroplating: Tin
Technical parameters/number of rows: 2
Technical parameters/number of pins: 32
Encapsulation parameters/installation method: Through Hole
Packaging parameters/pin spacing: 2.54 mm
External dimensions/length: 40.6 mm
External dimensions/width: 5.08 mm
External dimensions/height: 2.54 mm
External dimensions/pin spacing: 2.54 mm
Physical parameters/shell color: Black
Physical parameters/contact material: Phosphor Bronze
Physical parameters/operating temperature: -55℃ ~ 105℃
Physical parameters/shell material: Plastic
Other/Product Lifecycle: Active
Other/Manufacturing Applications: Industrial, -
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
Compliant with standards/REACH SVHC standards: No SVHC
Compliant with standard/REACH SVHC version: 2015/06/15
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
TSW-116-08-G-D
|
Samtec | 功能相似 |
SAMTEC TSW-116-08-G-D 板至板连接, 垂直, TSW系列, 32 触点, 针座, 2.54 mm, 通孔安装, 2 排
|
|||
TSW-116-08-L-D
|
Samtec | 功能相似 |
2.54mm 方柱管座接线端子束夹 - TSW 系列 TSW 系列印刷电路板通孔板对板方柱管座接线端子束夹，具有 2.54mm 节距、黑色玻璃填充聚酯绝缘体和磷青铜接线端子，带镀金触点。 这些印刷电路板板到板通孔方柱管座接线端子束夹提供各种配置，包括单排和双排、直向和直角，并可选择镀层和支柱长度。 这些 TSW 系列印刷电路板通孔管座接线端子的工作温度范围为 -55° 至 125°C。 带有 TSW-xxx-xx-x-S 部件号的 TSW 印刷电路板管座为单排。 带有 TSW-xxx-xx-x-D 部件号的 TSW 印刷电路板管座为双排。 带有 TSW-xxx-xx-L-x 部件号的 TSW 印刷电路板管座的支柱为 0.25μm 镀金，尾线上为无光泽镀锡。 带有 TSW-xxx-xx-G-x 部件号的 TSW 印刷电路板管座的支柱为 0.25μm 镀金，其余镀薄金。 带有 TSW-xxx-07-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 5.84mm，尾线长度为 2.54mm。 带有 TSW-xxx-08-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 5.84mm，尾线长度为 5.08mm。 带有 TSW-xxx-14-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 8.13mm，尾线长度为 2.79mm。 带有 TSW-xxx-17-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 15.74mm，尾线长度为 2.79mm。 带有 TSW-xxx-23-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 5.84mm，尾线长度为 2.92mm。 带有 TSW-xxx-26-x-x 部件号的 TSW 印刷电路板管座的接线端子高度为 5.84mm，尾线长度为 3.20mm。 ### 注 这些 TSW 系列印刷电路板通孔板对板方柱管座接线端子可与以下各项配接： BCS 标准盒插座 - 请参见库存号 766-6486（典型） CES 薄型插座条 - 请参见库存号 766-6600（典型） SLW 薄型插座条 - 请参见库存号 767-9408（典型） SSM 表面安装插座条 - 请参见库存号 765-5357（典型） SSQ 插座条 - 请参见库存号 765-5468（典型） SSW 插座条 - 请参见库存号 765-5593（典型） ### 2.54 mm 板对板和线对板 - Samtec
|
