Technical parameters/wavelength: 660 nm
Technical parameters/perspective: 30°
Technical parameters/peak wavelength: 660 nm
Technical parameters/test current: 20 mA
Technical parameters/forward voltage (Max): 1.85 V
Technical parameters/forward current (Max): 30 mA
Technical parameters/operating temperature (Max): 85 ℃
Technical parameters/operating temperature (Min): -40 ℃
Technical parameters/dissipated power (Max): 100 mW
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: T-1
External dimensions/packaging: T-1
Physical parameters/color: Red
Other/Product Lifecycle: Active
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
L-53SRC-DW
|
Kingbright | 功能相似 | T-1 |
LED Uni-Color Red 660nm 2Pin T-1 3/4
|
||
L-53SRC-E
|
Kingbright | 功能相似 | T-1 |
KINGBRIGHT L-53SRC-E 发光二极管, 红色, 通孔安装, T-1 3/4 (5mm), 20 mA, 1.85 V, 640 nm
|
||
L53SRC/E
|
Kingbright | 功能相似 | T-1 |
Standard LEDs - Through Hole
|
