Technical parameters/line gauge: 28 AWG
Technical parameters/rated voltage (DC): 300 V
Technical parameters/rated voltage (AC): 300 V
Technical parameters/rated current: 1 A
Technical parameters/insulation resistance: 10000 MΩ
Technical parameters/capacitors: 14 pF
Technical parameters/shielding: No
Technical parameters/number of cores: 25
Technical parameters/rated current (Max): 1 A
Technical parameters/operating temperature (Max): 105 ℃
Technical parameters/operating temperature (Min): -20 ℃
Technical parameters/rated voltage (Max): 300 V
Technical parameters/rated voltage: 300 V
Encapsulation parameters/Encapsulation: 100
Packaging parameters/pin spacing: 1.27 mm
External dimensions/length: 100 ft
External dimensions/height: 0.89 mm
External dimensions/packaging: 100
External dimensions/pin spacing: 1.27 mm
External dimensions/cable length: 30.48 m
External dimensions/thickness: 889 µm
Physical parameters/color: Gray
Physical parameters/conductor material: Tinned Copper
Physical parameters/shell material: PVC
Other/Product Lifecycle: Active
Other/Packaging Methods: Tape & Reel (TR)
Other/Manufacturing Applications: Computers & Computer Peripherals
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
Compliant with standards/REACH SVHC standards: No SVHC
Compliant with standard/REACH SVHC version: 2015/12/17
Customs information/ECCN code: EAR99
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
3365-25
|
3M | 功能相似 | 100 |
3M 3365-25 带状电缆, 扁平圆导体, 灰色, 25 芯, 28 AWG, 0.072 mm², 100 ft, 30.5 m
|
||
57040-2
|
TE Connectivity | 功能相似 | 100 |
WIRE AND CABLE, FLAT RIBBON CABLE, 25Conductor(S), 28AWG, 300V, ROHS COMPLIANT
|
||
NFCG-2825
|
PRO Power | 功能相似 | 100 |
PRO POWER NFCG-2825 带状电缆, 扁平, 灰色, 25 芯, 28 AWG, 0.072 mm², 100 ft, 30.5 m
|
