Technical parameters/rated voltage (DC): 18.0 V
Technical parameters/rated power: 1.50 kW
Technical parameters/halogen-free state: Halogen Free
Technical parameters/breakdown voltage: 17.1 V|17.1 V
Technical parameters/number of circuits: 1
Technical parameters/number of pins: 2
Technical parameters/dissipated power: 1500 W
Technical parameters/clamp voltage: 25.2 V
Technical parameters/Maximum reverse voltage (Vrrm): 15.3V
Technical parameters/test current: 1 mA
Technical parameters/maximum reverse breakdown voltage: 18.9 V
Technical parameters/peak pulse power: 1500 W
Technical parameters/minimum reverse breakdown voltage: 17.1 V
Technical parameters/operating temperature (Max): 175 ℃
Technical parameters/operating temperature (Min): -65 ℃
Technical parameters/operating temperature: -65℃ ~ 175℃
Encapsulation parameters/installation method: Through Hole
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: DO-201AD
External dimensions/length: 9.5 mm
External dimensions/diameter: 5.30 mm
External dimensions/packaging: DO-201AD
Physical parameters/operating temperature: -65℃ ~ 175℃ (TJ)
Other/Product Lifecycle: Active
Other/Packaging Methods: Each
Other/Manufacturing Applications: Automation & Process Control, Industrial, Universal, Communications & Networking, Computers & Computer Peripherals, Power Management, Consumer Electronics, Medical
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
Compliant with standard/REACH SVHC version: 2015/12/17
Customs information/ECCN code: EAR99
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
1.5KE18A
|
ON Semiconductor | 类似代替 | DO-201AD |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
YENJI | 类似代替 | DO-201AD |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
JXND | 类似代替 | DO-201 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
UNI-ROYAL | 类似代替 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
|||
|
1.5KE18A
|
Vishay Semiconductor | 类似代替 | Case 1.5KE |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
Multicomp | 类似代替 | DO-201 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
Diotec Semiconductor | 类似代替 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
|||
|
1.5KE18A
|
EIC | 类似代替 | DO-201 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18A
|
Brightking | 类似代替 | DO-201 |
1500瓦Mosorb齐纳瞬态电压抑制器 1500 Watt Mosorb Zener Transient Voltage Suppressors
|
||
1.5KE18ARL4G
|
Littelfuse | 类似代替 | DO-201AD |
1500W 齐纳瞬态电压抑制器（单向） SMC 系列设计用于保护电压敏感组件抵抗高电压和高能量瞬变。 它们具有极佳的钳位能力、高浪涌能力、低齐纳阻抗和快速响应时间。 峰值功率 − 1500W @ 1.0ms 3 类 ESD 等级> (16kV)/人体模型 最高钳位电压 @ 峰值脉冲电流 低泄漏 UL 497B，用于隔离回路保护 指定了最大温度系数 响应时间通常为 ### 瞬态电压抑制器，On Semiconductor
|
||
1.5KE18ARL4G
|
ON Semiconductor | 类似代替 | DO-201AD |
1500W 齐纳瞬态电压抑制器（单向） SMC 系列设计用于保护电压敏感组件抵抗高电压和高能量瞬变。 它们具有极佳的钳位能力、高浪涌能力、低齐纳阻抗和快速响应时间。 峰值功率 − 1500W @ 1.0ms 3 类 ESD 等级> (16kV)/人体模型 最高钳位电压 @ 峰值脉冲电流 低泄漏 UL 497B，用于隔离回路保护 指定了最大温度系数 响应时间通常为 ### 瞬态电压抑制器，On Semiconductor
|
||
|
|
Littelfuse | 类似代替 | DO-13 |
硅雪崩二极管 - 1500瓦金属轴向引线型瞬态电压抑制器 Silicon Avalanche Diodes - 1500 Watt Metal Axial Leaded Transient Voltage Suppressors
|
||
|
1N5639A
|
NJS | 类似代替 |
硅雪崩二极管 - 1500瓦金属轴向引线型瞬态电压抑制器 Silicon Avalanche Diodes - 1500 Watt Metal Axial Leaded Transient Voltage Suppressors
|
|||
1N5639A
|
Solid State | 类似代替 | DO-202AA |
硅雪崩二极管 - 1500瓦金属轴向引线型瞬态电压抑制器 Silicon Avalanche Diodes - 1500 Watt Metal Axial Leaded Transient Voltage Suppressors
|
