Technical parameters/rated voltage (DC): 100 V
Technical parameters/capacitors: 10 µF
Technical parameters/tolerances: ±20 %
Technical parameters/Ripple current: 54 mA
Technical parameters/operating temperature (Max): 105 ℃
Technical parameters/operating temperature (Min): -55 ℃
Technical parameters/rated voltage: 100 V
Encapsulation parameters/installation method: Through Hole
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: Radial, CAN
Packaging parameters/pin spacing: 2.5 mm
External dimensions/length: 11.2 mm
External dimensions/height: 11.2 mm
External dimensions/diameter: 6.30 mm
External dimensions/packaging: Radial, CAN
External dimensions/pin spacing: 2.5 mm
Physical parameters/medium materials: Aluminum Electrolytic
Physical parameters/operating temperature: -55℃ ~ 105℃
Other/Product Lifecycle: Unknown
Other/Packaging Methods: Bulk
Other/Lifespan (hours): 1000 h
Other/Manufacturing Applications: Industrial, consumer electronics, portable devices, power management, automotive use
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
Compliant with standards/REACH SVHC standards: No SVHC
Compliant with standard/REACH SVHC version: 2015/06/15
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
EKMG101ELL100MF11D
|
Nippon | 类似代替 |
UNITED CHEMI-CON EKMG101ELL100MF11D 铝电解电容； 10uF
|
|||
UVR2A100MED
|
Nichicon | 功能相似 | Radial, Can |
Nichicon VR 系列 Nichicon VR 系列铝电解电容器是高可靠性电容器，额定寿命长达 2000 小时。 VR 系列电容器提供高温度范围、高电压、低阻抗和高波纹电流。 高可靠性 高波纹电流 长寿命，长达 2000 小时 无铅回流焊接 电容容差 (%) | 20 ---|--- 温度范围 ( ° C) | -40 至 +85 泄漏电流 | 0.01 CV 或 3μA，以较大值为准 85ºC 条件下的预期寿命 | 2000 小时
|
||
UVZ2A100MED1TD
|
Nichicon | 类似代替 | 剪切带 |
NICHICON UVZ2A100MED1TD 铝电解电容, 10uF, 100V, 径向引线
|
