Technical parameters/number of pins: 2
Technical parameters/forward voltage: 0.9 V
Technical parameters/thermal resistance: 20℃/W (RθJA)
Technical parameters/reverse recovery time: 2.5 µs
Technical parameters/Maximum reverse voltage (Vrrm): 200 V
Technical parameters/forward current: 6 A
Technical parameters/Maximum forward surge current (Ifsm): 400 A
Technical parameters/maximum reverse leakage current (Ir): 5 uA
Technical parameters/forward voltage (Max): 1.25 V
Technical parameters/forward current (Max): 6 A
Technical parameters/operating temperature (Max): 150 ℃
Technical parameters/operating temperature (Min): -50 ℃
Encapsulation parameters/installation method: Through Hole
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: P-600
External dimensions/length: 9.1 mm
External dimensions/width: 9.1 mm
External dimensions/height: 9.1 mm
External dimensions/packaging: P-600
Physical parameters/operating temperature: -50℃ ~ 150℃
Other/Product Lifecycle: Active
Other/Packaging Methods: Tape & Reel (TR)
Other/Minimum Packaging: 800
Compliant with standards/RoHS standards:
Compliant with standards/lead standards: Lead Free
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
|
|
VISHAY | 完全替代 | P600 |
VISHAY GI752-E3 标准恢复二极管, 单, 200 V, 6 A, 1.25 V, 2.5 µs, 400 A
|
||
GI752-E3
|
Vishay Semiconductor | 完全替代 | P600 |
VISHAY GI752-E3 标准恢复二极管, 单, 200 V, 6 A, 1.25 V, 2.5 µs, 400 A
|
||
GI752-E3/73
|
VISHAY | 类似代替 | P-600 |
Diode Switching 200V 6A 2Pin Case P600 Ammo
|
||
|
|
VISHAY | 完全替代 | P-600 |
Diode Switching 200V 6A 2Pin Case P-600 T/R
|
