Technical parameters/rated voltage (DC): 225 V
Technical parameters/rated voltage (AC): 175 V
Technical parameters/capacitors: 580 pF
Technical parameters/clamp voltage: 455 V
Technical parameters/operating temperature (Max): 85 ℃
Technical parameters/operating temperature (Min): -40 ℃
Technical parameters/rated voltage (DC Max): 225 V
Technical parameters/rated voltage (AC Max): 175 V
Encapsulation parameters/Encapsulation: Sheet shaped 13mm
External dimensions/packaging: Sheet shaped 13mm
External dimensions/thickness: 5.6 mm
Physical parameters/operating temperature: -40℃ ~ 85℃
Other/Product Lifecycle: Unknown
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/REACH SVHC standards: No SVHC
Compliant with standard/REACH SVHC version: 2015/06/15
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
ERZV14D271
|
Panasonic | 功能相似 | 片状 14mm |
ZNR 系列，14mm 直径，Panasonic 相对于紧凑的结构而言，具有较大的浪涌电流处理能力 相对于标准变速器而言，提升了 2 浪涌电流处理能力 类型 | 直径 （标称 /最大）(mm) | 节距 (mm) | 高度（印刷电路板上） (mm) ---|---|---|--- ERZV05 | 5 / 7 | 5 ±1 | 10 ERZV07 | 7 / 8.5 | 5 ±1 | 11.5 ERZV10 | 10 / 12.5 | 7.5 ±1 | 15.5 ERZV14 | 14 / 16 | 7.5 ±1 | 19 ERZV20 | 20 / 21.5 | 10 ±1 | 24.5 ### 瞬态电压抑制器 (径向金属氧化物变阻器)
|
