Model 1N5920BG

Description ON SEMICONDUCTOR 1N5920BG Single tube diode Zener, 6.2 V, 3 W, DO-41, 5%, 2-pin, 200 ° C

Brand: ON Semiconductor

Packaging DO-41

Delivery time

Packaging method Bulk

Standard packaging quantity 1

5+:

$ 3.0686

25+:

$ 2.8413

50+:

$ 2.6821

100+:

$ 2.6140

500+:

$ 2.5685

2500+:

$ 2.5117

5000+:

$ 2.4889

10000+:

$ 2.4548

Price	$ 3.0686	$ 2.8413	$ 2.6821	$ 2.6140	$ 2.5685
Start batch production	5+	25+	50+	100+	500+

Freight charges： In stock Freight rate：$13.00

Quantity：

Inventory(6585) Minimum order quantity(5)

Add to Cart Buy now

Welcome to use ICGOODFIND AI Assistant

Chip AI consultant

Download related files

PDF

Specification parameters
PDF
Silk screen printing
Review and share the purchase （0 ）
Product inquiry (0)
Selection Manual
Adapter model (0)

Technical parameters/rated voltage (DC): 6.20 V

Technical parameters/tolerances: ±5 %

Technical parameters/rated power: 3.00 W

Technical parameters/halogen-free state: Halogen Free

Technical parameters/breakdown voltage: 6.20 V

Technical parameters/number of pins: 2

Technical parameters/forward voltage: 1.5V @200mA

Technical parameters/dissipated power: 3 W

Technical parameters/test current: 60.5 mA

Technical parameters/forward current: 200 mA

Technical parameters/voltage regulation value: 6.2 V

Technical parameters/forward voltage (Max): 1.5V @200mA

Technical parameters/rated power (Max): 3 W

Technical parameters/operating temperature (Max): 200 ℃

Technical parameters/operating temperature (Min): -65 ℃

Technical parameters/working junction temperature (Max): 200 ℃

Technical parameters/dissipated power (Max): 3 W

Encapsulation parameters/installation method: Through Hole

Package parameters/number of pins: 2

Encapsulation parameters/Encapsulation: DO-41

External dimensions/length: 5.2 mm

External dimensions/width: 2.7 mm

External dimensions/height: 2.7 mm

External dimensions/packaging: DO-41

Physical parameters/operating temperature: -65℃ ~ 200℃

Other/Product Lifecycle: Active

Other/Packaging Methods: Bulk

Compliant with standards/RoHS standards: RoHS Compliant

Compliant with standards/lead standards: Lead Free

Compliant with standards/REACH SVHC standards: No SVHC

Compliant with standard/REACH SVHC version: 2016/06/20

Customs information/ECCN code: EAR99

Alternative material

Model	Brand	Similarity	Encapsulation	Introduction	Data manual
1N5920B	Taitron	完全替代		3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators
1N5920B	Motorola	完全替代		3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	EIC	完全替代	DO-41	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	Microsemi	完全替代	DO-204AL	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	Micro Commercial Components	完全替代	DO-41	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	Multicomp	完全替代	DO-15	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	ON Semiconductor	完全替代	DO-204AL	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920B	TDK	完全替代		3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators
1N5920BG	Microsemi	功能相似	DO-41	ON SEMICONDUCTOR 1N5920BG 单管二极管齐纳, 6.2 V, 3 W, DO-41, 5 %, 2 引脚, 200 °C	PDF
1N5920BG	ON Semiconductor	功能相似	DO-41	ON SEMICONDUCTOR 1N5920BG 单管二极管齐纳, 6.2 V, 3 W, DO-41, 5 %, 2 引脚, 200 °C	PDF
1N5920BRL	ON Semiconductor	完全替代	DO-41	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
1N5920BRLG	ON Semiconductor	完全替代	DO-41-2	3 W DO- 41 Surmetic TM 30齐纳稳压器 3 W DO−41 Surmetic TM 30 Zener Voltage Regulators	PDF
BZX85C6V2	Central Semiconductor	功能相似	DO-41	齐纳二极管 1W，BZX85C 系列，Fairchild Semiconductor ### 齐纳二极管，Fairchild Semiconductor
BZX85C6V2	ON Semiconductor	功能相似	DO-41	齐纳二极管 1W，BZX85C 系列，Fairchild Semiconductor ### 齐纳二极管，Fairchild Semiconductor	PDF
BZX85C6V2	Fairchild	功能相似	DO-41-2	齐纳二极管 1W，BZX85C 系列，Fairchild Semiconductor ### 齐纳二极管，Fairchild Semiconductor	PDF
