Technical parameters/rated voltage (DC): 200 V
Technical parameters/capacitors: 47 µF
Technical parameters/tolerances: ±20 %
Technical parameters/Ripple current: 220 mA
Technical parameters/operating temperature (Max): 105 ℃
Technical parameters/operating temperature (Min): -40 ℃
Technical parameters/rated voltage: 200 V
Encapsulation parameters/installation method: Through Hole
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: Paper tape and paper wheel
Packaging parameters/pin spacing: 5 mm
External dimensions/length: 25 mm
External dimensions/height: 25 mm
External dimensions/diameter: 12.5 mm
External dimensions/packaging: Paper tape and paper wheel
External dimensions/pin spacing: 5 mm
Physical parameters/medium materials: Aluminum Electrolytic
Physical parameters/operating temperature: -40℃ ~ 105℃
Other/Product Lifecycle: Active
Other/Packaging Methods: Tape & Reel (TR)
Other/Lifespan (hours): 7000h @105℃
Other/Manufacturing Applications: General
Compliant with standards/RoHS standards: RoHS Compliant
Compliant with standards/lead standards: Lead Free
Compliant with standard/REACH SVHC version: 2015/12/17
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
EEU-EB2D470
|
Panasonic | 功能相似 | Radial, Can |
PANASONIC ELECTRONIC COMPONENTS EEU-EB2D470 铝制电解电容, 47UF
|
||
EEUEE2D470
|
Panasonic | 功能相似 | Radial, Can |
EE 系列 Panasonic EE 系列 A 型电解电容器的耐受性可达 8000 至 10000 小时（取决于盒体尺寸）。 与 Panasonic ED 系列相比，这些径向电容器可在高频率下提供高出 40% 的波纹电流。 高波纹电流 极佳的耐受性 低阻抗 ### 应用 Panasonic EE 系列 A 型电解电容器特凭借其高可靠性，可用于工业仪器。 ### 径向 105°C
|
||
UPW2D470MHD
|
Nichicon | 完全替代 | Radial, Can |
PW 系列 47 uF 200 V 20 % 通孔 径向 铝电解电容
|
