Technical parameters/rated voltage (DC): | 6.30 V |
|
Technical parameters/capacitance: | 1200 µF |
|
Technical parameters/tolerances: | ±20 % |
|
Technical parameters/Ripple current: | 1290 mA |
|
Technical parameters/operating temperature (Max): | 105 ℃ |
|
Technical parameters/operating temperature (Min): | -40 ℃ |
|
Technical parameters/accuracy: | ±20 % |
|
Technical parameters/rated voltage: | 6.3 V |
|
Encapsulation parameters/installation method: | Through Hole |
|
Package parameters/number of pins: | 2 |
|
Encapsulation parameters/Encapsulation: | direct insertion |
|
Packaging parameters/pin spacing: | 5 mm |
|
Dimensions/Height: | 12.5 mm |
|
Dimensions/Diameter: | 10.0 mm |
|
Dimensions/Packaging: | direct insertion |
|
Dimensions/Pin Spacing: | 5 mm |
|
Physical parameters/medium materials: | Aluminum Electrolytic |
|
Physical parameters/operating temperature: | -40℃ ~ 105℃ |
|
Other/Product Lifecycle: | Unknown |
|
Other/Packaging Methods: | Each |
|
Other/Lifespan (hours): | 6000h @105℃ |
|
Other/Manufacturing Applications: | Industrial, Power Management, Consumer Electronics, Consumer Electronics, Industrial, Portable Equipment, Power Management, Portable Devices |
|
Compliant with standards/RoHS standards: | RoHS Compliant |
|
Compliant with the REACH SVHC standard: | No SVHC |
|
Compliant with standard/REACH SVHC version: | 2015/06/15 |
|
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
EEUFC0J122
|
Panasonic | 类似代替 | Radial, Can |
PANASONIC ELECTRONIC COMPONENTS EEUFC0J122 铝电解电容, AEC-Q200 FC系列, 1200 µF, ± 20%, 6.3 V, 10 mm, 径向引线
|
||
EEUFM0J122L
|
Panasonic | 类似代替 | Radial, Can |
PANASONIC ELECTRONIC COMPONENTS EEUFM0J122L 铝电解电容, FM系列, 1200 µF, ± 20%, 6.3 V, 8 mm, 径向引线
|
