Technical parameters/rated voltage (DC): | 450 V |
|
Technical parameters/capacitance: | 56 µF |
|
Technical parameters/tolerances: | ±20 % |
|
Technical parameters/Ripple current: | 510 mA |
|
Technical parameters/operating temperature (Max): | 105 ℃ |
|
Technical parameters/operating temperature (Min): | -25 ℃ |
|
Technical parameters/rated voltage: | 450 V |
|
Encapsulation parameters/installation method: | Through Hole |
|
Package parameters/number of pins: | 2 |
|
Encapsulation parameters/Encapsulation: | Radial, CAN |
|
Packaging parameters/pin spacing: | 7.5 mm |
|
Dimensions/Height: | 30 mm |
|
Dimensions/Diameter: | 16.0 mm |
|
Dimensions/Packaging: | Radial, CAN |
|
Dimensions/Pin Spacing: | 7.5 mm |
|
Physical parameters/operating temperature: | -25℃ ~ 105℃ |
|
Other/Product Lifecycle: | Obsolete |
|
Other/Packaging Methods: | Each |
|
Other/Lifespan (hours): | 12000h @105℃ |
|
Other/Manufacturing Applications: | Power Management, Consumer Electronics, Industrial, General, Power Management, Portable Devices, Consumer Electronics, Industrial |
|
Compliant with standards/RoHS standards: | RoHS Compliant |
|
Compliant with standards/lead standards: | Lead Free |
|
Compliant with the REACH SVHC standard: | No SVHC |
|
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
EEU-EE2W560
|
Panasonic | 功能相似 | Radial, Can |
PANASONIC ELECTRONIC COMPONENTS EEU-EE2W560 铝电解电容, EE系列, 56 µF, ± 20%, 450 V, 18 mm, 径向引线
|
||
EEUEE2W560
|
Panasonic | 功能相似 |
PANASONIC ELECTRONIC COMPONENTS EEUEE2W560 铝电解电容, EE系列, 56 µF, ± 20%, 450 V, 18 mm, 径向引线
|
