Technical parameters/number of contacts: | 4 |
| |||||||||||||||||||
Technical parameters/polarity: | Male |
| |||||||||||||||||||
Technical parameters/Contact electroplating: | Tin |
| |||||||||||||||||||
Technical parameters/rated current: | 3 A |
| |||||||||||||||||||
Technical parameters/number of rows: | 1 |
| |||||||||||||||||||
Technical parameters/direction: | Vertical |
| |||||||||||||||||||
Technical parameters/Flammability level: | UL 94 V-0 |
| |||||||||||||||||||
Technical parameters/number of pins: | 4 |
| |||||||||||||||||||
Technical parameters/rated current (Max): | 4.2A/contact |
| |||||||||||||||||||
Technical parameters/rated voltage (Max): | 250 VAC |
| |||||||||||||||||||
Technical parameters/rated voltage: | 250 VAC |
| |||||||||||||||||||
Encapsulation parameters/installation method: | Through Hole |
| |||||||||||||||||||
Encapsulation parameters/Encapsulation: | - |
| |||||||||||||||||||
Dimensions/Length: | 12.5 mm |
| |||||||||||||||||||
Dimensions/Width: | 6.4 mm |
| |||||||||||||||||||
Dimensions/Height: | 8.8 mm |
| |||||||||||||||||||
Dimensions/Packaging: | - |
| |||||||||||||||||||
Physical parameters/shell color: | White |
| |||||||||||||||||||
Physical parameters/color: | Natural |
| |||||||||||||||||||
Physical parameters/contact material: | Brass |
| |||||||||||||||||||
Physical parameters/operating temperature: | -55℃ ~ 105℃ |
| |||||||||||||||||||
Physical parameters/shell material: | Nylon 6/6 |
| |||||||||||||||||||
Other/Product Lifecycle: | Active |
| |||||||||||||||||||
Other/Packaging Methods: | Bag |
| |||||||||||||||||||
Other/Manufacturing Applications: | Lighting, Industrial, HVAC, Power, Lighting, General, Industrial, Lighting, Industrial, Commercial, Commercial |
| |||||||||||||||||||
Compliant with standards/RoHS standards: | RoHS Compliant |
| |||||||||||||||||||
Compliant with standards/lead standards: | Lead Free |
| |||||||||||||||||||
Compliant with standards/ELV standards: | Compliant |
| |||||||||||||||||||
Compliant with the REACH SVHC standard: | No SVHC |
| |||||||||||||||||||
Compliant with standard/REACH S Alternative material
