Technical parameters/rated current: | 3.00 A |
|
Technical parameters/inductance: | 22 µH |
|
Technical parameters/self harmonic frequency: | 110 MHz |
|
Technical parameters/resonance frequency: | 110 MHz |
|
Technical parameters/inductance tolerance: | ±20 % |
|
Technical parameters/testing frequency: | 0.1 MHz |
|
Technical parameters/rated current (DC): | 3 A |
|
Technical parameters/Resistance (DC Max): | 0.07 Ω |
|
Encapsulation parameters/installation method: | Axial |
|
Package parameters/number of pins: | 2 |
|
Dimensions/Length: | 27.4 mm |
|
Dimensions/Diameter: | 7.00 mm |
|
Other/Product Lifecycle: | Active |
|
Other/Packaging Methods: | Tape & Reel (TR) |
|
Other/Manufacturing Applications: | RF Communications, Communications and Networks, Communications& Networking |
|
Compliant with standards/RoHS standards: | RoHS Compliant |
|
Compliant with standards/lead standards: | Lead Free |
|
Compliant with the REACH SVHC standard: | No SVHC |
|
Compliant with standard/REACH SVHC version: | 2015/06/15 |
|
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
B82111E0000C022
|
Epcos | 功能相似 | Axial |
VHF Choke Wirewound 22uH 20% 100kHz Ferrite 3A 70mOhm DCR AXL T/R
|
||
|
|
TDK | 功能相似 | Axial |
VHF Choke Wirewound 22uH 20% 100kHz Ferrite 3A 70mOhm DCR AXL T/R
|
||
B82111EC22
|
Epcos | 类似代替 | Axial |
EPCOS B82111EC22 轴向引线高频电感器, VHF扼流, B82111E系列, 22 µH, ± 20%, 0.07 ohm, 3 A, 110 MHz
|
