Technical parameters/breakdown voltage: 7.51 V
Technical parameters/number of pins: 2
Technical parameters/dissipated power: 1.5 kW
Technical parameters/clamp voltage: 11.3 V
Technical parameters/Maximum reverse voltage (Vrrm): 6.4V
Technical parameters/test current: 10 mA
Technical parameters/maximum reverse breakdown voltage: 7.88 V
Technical parameters/peak pulse power: 1500 W
Technical parameters/minimum reverse breakdown voltage: 7.13 V
Technical parameters/operating temperature (Max): 175 ℃
Technical parameters/operating temperature (Min): -55 ℃
Technical parameters/operating temperature: -55℃ ~ 175℃
Encapsulation parameters/installation method: Through Hole
Package parameters/number of pins: 2
Encapsulation parameters/Encapsulation: DO-201
External dimensions/length: 9.5 mm
External dimensions/packaging: DO-201
Other/Product Lifecycle: Active
Other/Packaging Methods: Tape & Reel (TR)
Other/Minimum Packaging: 1400
Compliant with standards/RoHS standards:
Compliant with standards/lead standards: Lead Free
Customs information/ECCN code: EAR99
| Model | Brand | Similarity | Encapsulation | Introduction | Data manual | |
|---|---|---|---|---|---|---|
1.5KE7.5A-E3/51
|
VISHAY | 功能相似 | DO-201AA |
1.5KE Series 1500W 7.5V Uni-Directional Through Hole TVS Diode - DO-201AA
|
||
|
1.5KE7.5A-E3/73
|
VISHAY | 功能相似 | DO-201AA |
Diode TVS Single Uni-Dir 6.4V 1.5kW 2Pin Case 1.5KE Ammo
|
||
1N6268A-E3/54
|
Vishay Semiconductor | 功能相似 | DO-201AA |
ESD 抑制器/TVS 二极管 1500W 7.5V Unidirect
|
